H111N
MAILON
8536500000
PC
86*86mm
250V~
10AX
EU standard
white, ivory, black, silver, golden
square
IP20
control light on /off
V1
poly bag + inner box+carton
What's the Flush mounted switch socket?
In the electrical switch decoration, switch socket is divided into surface and flush series according to the way of installation.
Here we are mainly in discuss flush mounted series switch socket:
1.Installation
The flush mounted switch socket need to buy the wall box firstly,before you start decoration you need embed the wall box to the hole which already digged on the wall, after all decoration work finished install the switch socket into the wall box, it need professional electrician do the switch socket installation work.
For flush mounted switch socket ,there will be only wall socket plate exposure on the wall surface after installation, switch socket base already hidden into the wall box.
In order to future maintenance you’d better keep the wiring diagram of electricity layout in advance in order to prevent future maintenance to drill hole on the wall or hit the wire to cause the short circuit when install something,decoration is troublesome, maintenance is more troublesome, and sometimes the walls need to be taken apart again.
2.Wire connection
Flush mounted switch socket can be divided into screw type and fast type according to wire connection way.
Screw type switch socket series adopt press board structure design, it is a very stable structure, there will no circuit shortage situation happen under this structure;
Fast type switch socket also is called screwless type series, it is terminal structure, you just need press the terminal insert the cable into the hole then loose the terminal wire connection is done,time is very short,but this type switch socket has strict request for the cable, if the cable quality is not qualified, the terminal can not fix the cable very stable, so there will be circuit accident happen.
The flush switch socket of HMN-MAILONdesign adopt 1st press board structure, use special arch structure which is more secure and firm in stability, all switch is designed with LED indicator, much more friendly and energy-saving than old neon light;All socket use high grade phosphor copper make sure high performance conductivity
What's the Flush mounted switch socket?
In the electrical switch decoration, switch socket is divided into surface and flush series according to the way of installation.
Here we are mainly in discuss flush mounted series switch socket:
1.Installation
The flush mounted switch socket need to buy the wall box firstly,before you start decoration you need embed the wall box to the hole which already digged on the wall, after all decoration work finished install the switch socket into the wall box, it need professional electrician do the switch socket installation work.
For flush mounted switch socket ,there will be only wall socket plate exposure on the wall surface after installation, switch socket base already hidden into the wall box.
In order to future maintenance you’d better keep the wiring diagram of electricity layout in advance in order to prevent future maintenance to drill hole on the wall or hit the wire to cause the short circuit when install something,decoration is troublesome, maintenance is more troublesome, and sometimes the walls need to be taken apart again.
2.Wire connection
Flush mounted switch socket can be divided into screw type and fast type according to wire connection way.
Screw type switch socket series adopt press board structure design, it is a very stable structure, there will no circuit shortage situation happen under this structure;
Fast type switch socket also is called screwless type series, it is terminal structure, you just need press the terminal insert the cable into the hole then loose the terminal wire connection is done,time is very short,but this type switch socket has strict request for the cable, if the cable quality is not qualified, the terminal can not fix the cable very stable, so there will be circuit accident happen.
The flush switch socket of HMN-MAILONdesign adopt 1st press board structure, use special arch structure which is more secure and firm in stability, all switch is designed with LED indicator, much more friendly and energy-saving than old neon light;All socket use high grade phosphor copper make sure high performance conductivity
